Pioneer TS-A4671F 4-Way, 210W

by Pioneer
Original price €98.00 - Original price €98.00
Original price
€98.00
€98.00 - €98.00
Current price €98.00

Pioneer TS-A4671F — 4 x 6 inch 4-Way Coaxial System (210W).

Main features

  • Diameter Size: 4 x 6 inch
  • Maximum input power: 210 W
  • Nominal input power: 30 W
  • Impedance: 4 Ω

Product features

Pioneer TS-A4671F

Pioneer TS-A4671F — 4 x 6 inch 4-Way Coaxial System (210W).

Pioneer TS-A4671F

Coaxial Speakers

Multiple drivers share a single speaker assembly for a compact installation.

Coaxial Speakers

IMPP™ Cone

A lightweight, rigid Injection Moulded Polypropylene cone supports controlled driver movement.

IMPP™ Cone

Open & Smooth™

Pioneer’s driver design aims for a smooth transition between midrange and treble and a broad listening area.

Open & Smooth™

Dimensions and installation

Dimensions and installation

Detailed specifications

Key Features

  • Series: A-Series
  • Diameter Size: 4 x 6 inch
  • Maximum input power: 210 W
  • Nominal input power: 30 W
  • Frequency response: 34 Hz - 49,000 Hz
  • Sensitivity: 88 dB
  • Impedance: 4 Ω
  • Dimensions: 158 mm (W) x 61 mm (H) x 102 mm (D)
  • Open & Smooth™: Yes
  • IMPP™ Composite Cone: Yes
  • Magnets: Ferrite
  • Woofer material: Carbon & Mica reinforced Injection Molded PolyPropylene (IMPP™) Cone

Other Specifications

  • Cut-out Hole: 95 x 153 mm
  • Mounting Depth: 42 mm
  • Speaker Grill: Not Included
  • Weight: 0.93 kg

Downloads

  • Installation Manuals (Dutch)Open
  • Compliance Documents (UK Declaration Of Conformity)Open
  • Compliance Documents (EU Declaration Of Conformity)Open
  • Addendums (English, French, German, Italian, Spanish, Portuguese, Russian, Arabic)Open
