MX-A5200
by Yamaha
Original price
€0.00
-
Original price
€0.00
Original price
€0.00
€0.00
-
€0.00
Current price
€0.00
11 ch AVENTAGE power amplifier pursuit for purity of sound and unsurpassed flexibility.
- AVENTAGE 11-channel power amplifier
- Supports Bridge-Tied Load (BTL) configuration for 2 x front channels
- 27,000 uF custom block capacitors
- Bi-amping capability with channel selector
- High-quality gold-plated speaker terminals
- Noise-resistant XLR balanced connections
| MX-A5200 | ||
|---|---|---|
| Amplifier Section | Channel | 11 |
| Rated Output Power (1kHz, 1ch driven) | 290 W (4 ohm, 0.9% THD [European Model]), 230 W (6 ohm, 0.9% THD), 190 W (8 ohm, 0.9% THD) | |
| Rated Output Power (1kHz, 2ch driven) | 170 W (8 ohm, 0.9% THD) | |
| Rated Output Power (1kHz, 2ch driven, bridged connection) | 240 W (8 ohm, 0.9% THD) | |
| Rated Output Power (20Hz-20kHz, 2ch driven) | 170 W (6 ohm, 0.06% THD), 150 W (8 ohm, 0.06% THD) | |
| Rated Output Power (20Hz-20kHz, 2ch driven, bridged connection) | 200 W (8 ohm, 0.06% THD) | |
| Maximum Effective Output Power (1kHz, 1ch driven) (JEITA) | 280 W (6 ohm, 10% THD), 230 W (8 ohm, 10% THD) | |
| Dynamic Power per Channel (8/6/4/2 ohms) | 190 / 250 / 350 / 500 W | |
| Audio Features | A.R.T. Wedge | Yes |
| BTL connection | Yes | |
| Bi-amp capability | Yes | |
| Digital ToP-ART / High Current Amplification | Three-stage Darlington Power Stage | |
| Current Feedback Amplifier Circuit | Yes | |
| Connectivity | Analog Audio Input/Output | XLR Balance: 11 / 0, RCA Unbalance: 11 / 0 |
| Zone Control | +12V Trigger Output | Out:1, Trigger in / Through: 1 / 1 |
| General | Standby Power Consumption (IR only) | 0.1 W (typical) |
| Auto Power Standby | Yes (ON / OFF switch) | |
| Dimensions (W x H x D) | 435 x 211 x 464 mm; 17-1/8” x 8-1/4” x 18-1/4” | |
| Weight | 26.4 kg; 58.2 lbs. | |
| Power Consumption | 650 W | |
